N2XRY 33KV 3 Core Cable XLPE Medium Voltage Cables 500 Sq Mm

Product Categories
Nuoxing Cable Co., Ltd
Contact Now

N2XRY 33KV 3 Core Cable XLPE Medium Voltage Cables 500 Sq Mm

  • 1
  • 2

Brand Name : Nupxing

Certification : CE/CCC/ISO9001

Place of Origin : China

MOQ : 100

Price : 10-100

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 km per month

Delivery Time : 10-20 days

Packaging Details : standard export packing in wooden drums or boxes

Model Number : N2XRY

Product Name : Medium Voltage Cables

Insulation material : XLPE

Conductor material : Copper

Rated voltage : 35KV and below

Type : Medium Voltage

Jacket : PVC

Purpose : Signal Transmission

Standard : IEC60502

Contact Now

33KV XLPE 3 Core Power Cable Steel Wire Armored Medium Voltage Cables

Application:

These cables are designed for power distribution in the range of rated voltage Uo/U, from 1.8/3KV to 26/35KV, with a frequency of 50Hz. It is mainly used for laying in water or soil with a large drop. The cable can withstand considerable tension. It is currently widely used in urban power grids, mines and factories.

Use characteristics:


- The rated power frequency voltage Uo/U is 0.6/1kV.
- The allowable long-term working temperature of the cable conductor is 90℃
- Allowable temperature of cable conductor during short circuit (long duration no more than 5s): 250℃
- The ambient temperature during cable laying should not be lower than 0°C.
- The bending diameter of a multi-core cable is not less than 15 times the outer diameter of the cable, and the bending diameter of a single-core cable is not less than 20 times the outer diameter of the cable.

Product name Medium Voltage Cables
Certifications CE/CCC/ISO
Standard IEC60502-2
Rated Voltage 6-35 KV
Conductor material Copper/Aluminum
Insulation Material XLPE
Armoured Material None/Steel Tape/Steel wire
Jacket Material PVC
Number of cores 1 or 3
Section area 25 35 50 70 95 120 150 185 240 300 400 500 sqmm

N2XRY 33KV 3 Core Cable XLPE Medium Voltage Cables 500 Sq Mm
